Description

Product Code :RG20BT (510mm)

OVERALL (including swing away legrests)
660mm (W)
1000mm (D)
930mm (H)

OVERALL FOLDED (legrests removed)
245mm (W) x 700mm (L) x 740mm (H)

Seat (W – between armrests)
510mm (W)
420mm (D)
520mm (H)

ARMRESTS (H – from seat)
300mm (L) x 50mm (D) x 220mm (H)

BACKREST
420mm (W) x 390mm (H)

WHEELS (flat free)
ø200mm / 8” (Front)
ø300mm / 12” (Rear)

MAIN FRAME WEIGHT (without legrests)
10.2kg

LEGREST WEIGHT
0.6kg (each)

MAX USER WEIGHT
127kg
